When manufacturing precision components, choosing between Spritzgießen and die casting depends on material requirements, production volume, and part complexity. Both processes offer unique advantages for different applications.
Process Overview
Die casting injects molten metal (aluminum, zinc, magnesium) into steel molds under high pressure. Injection molding does the same with thermoplastics like nylon, POM, or PEEK.
Key Differences
| Factor | Druckgießen | Spritzgießen |
|---|---|---|
| Material | Metal (Al, Zn, Mg) | Technische Kunststoffe |
| Weight | Heavier | Lighter (40-70% reduction) |
| Tooling Cost | Higher ($30k-$150k) | Lower ($10k-$50k) |
| Cycle Time | 15-60 seconds | 10-45 seconds |
When to Choose Injection Molded Plastics
Nylon injection molding is preferred when:
- Weight reduction is critical (automotive, aerospace)
- Electrical insulation is required
- Chemical resistance to specific environments
- Lower tooling investment for mid-range volumes
- Design requires complex features (undercuts, threads)
Material Advantages
Engineering plastics offer advantages over die cast metals:
- Corrosion resistance — no rust or oxidation
- Design freedom — snap-fits, living hinges, integrated fasteners
- Vibration damping — quieter operation
- Lower secondary operations — no machining or surface treatment needed
Why Choose Our Injection Molding Services
Injection molding delivers consistent, high-volume plastic parts at low per-unit cost. Our facilities combine advanced molding equipment with in-house tooling capabilities:
- 80+ mold machines — high-speed CNC machining centers, EDM, wire-cutting, vacuum casting
- Large mold capacity — worktable up to 2500mm × 1500mm for large automotive and appliance molds
- ±0.01mm mold precision — precision control from mold design to mass production
- MOQ 1 set — prototype tooling and R&D samples without high mold costs
- Fast tooling — standard molds in 3–5 working days; first samples within 7 days
- Mass production — monthly output up to 500,000 pieces per product category
Our in-house mold making eliminates the communication gap between molder and toolroom, reducing revision cycles and ensuring your mold is optimized for your specific material and part design.
Planning a new product? Share your part drawings and annual volume targets for a comprehensive production cost analysis.
Häufig gestellte Fragen
Can injection molded parts replace die cast components?
Yes, in many applications. Engineering plastics like glass-filled nylon can achieve comparable strength-to-weight ratios. Design modifications may be needed to account for different material properties.
What is the cost crossover point between die casting and injection molding?
Injection molding typically has lower tooling cost but higher material cost. For parts under 500g in volumes of 1,000-50,000 units, injection molding is often more economical. Larger metal parts may favor die casting.
How do tolerances compare between die casting and injection molding?
Die casting typically achieves ±0.15mm, injection molding ±0.1mm. Both can achieve tighter tolerances with optimized mold design and process control.
Can I prototype before committing to tooling?
Yes. CNC machined or 3D printed prototypes allow testing before mold investment. Some molders offer soft tooling (aluminum molds) for bridge production.
