PA12 CF30 Technical Data (Estimated Typical Values)
| Eigentum | Wert | Test Standard |
|---|---|---|
| Kohlenstofffaser Inhalt | 30% | ISO 1172 |
| Zugfestigkeit | 160 - 180 MPa | ISO 527 |
| Biegemodus | 13,000 – 15,000 MPa | ISO 178 |
| Kerbschlagzähigkeit | 7 - 10 kJ/m² | ISO 180 |
| HDT @1,8 MPa | 160 - 170 °C | ISO 75 |
| Wasserabsorption (24h) | ~0.6% | ISO 62 |
| Volumenwiderstand | 10^2 - 10^4 Ω-cm | IEC 60093 |
PA12 CF Series Performance Comparison Table (Estimated Typical Values)
| Eigentum | PA12 CF10 | PA12 CF20 | PA12 CF30 | PA12 CF40 | PA12 CF50 |
|---|---|---|---|---|---|
| Kohlenstofffaser Inhalt | 10% | 20% | 30% | 40% | 50% |
| Zugfestigkeit | 110 – 130 MPa | 140 - 160 MPa | 160 - 180 MPa | 175 - 195 MPa | 190 – 210 MPa |
| Biegemodus | 7.000 - 8.500 MPa | 10.000 - 12.000 MPa | 13,000 – 15,000 MPa | 16,000 – 18,000 MPa | 19,000 – 22,000 MPa |
| Kerbschlagzähigkeit | 9 - 12 kJ/m² | 8 - 11 kJ/m² | 7 - 10 kJ/m² | 6 - 9 kJ/m² | 5 - 8 kJ/m² |
| HDT @1,8 MPa | 150 – 160 °C | 155 - 165 °C | 160 - 170 °C | 165 - 175 °C | 170 - 180 °C |
| Wasserabsorption (24h) | ~0.7% | ~0.65% | ~0.6% | ~0.55% | ~0.5% |
| Volumenwiderstand | 10^4 – 10^6 Ω·cm | 10^3 - 10^5 Ω-cm | 10^2 - 10^4 Ω-cm | 10^1 - 10^3 Ω-cm | 10^0 - 10^2 Ω-cm |
| Schlüsselprofil | Stiffness & stability upgrade | Ausgewogene Leistung | Structural benchmark in harsh env. | High rigidity & precision | Maximale Leistung |
Anmerkung: Alle Angaben sind geschätzte typische Werte zum Vergleich. Die genauen Eigenschaften müssen anhand des offiziellen Datenblatts überprüft werden.
PA12 CF30 Key Advantages
✅ Benchmark for Demanding Environmental Structural Use: Represents the optimal balance of high stiffness, good toughness, and top-tier resistance to moisture, chemicals, and hydrolysis.
✅ Unwavering Dimensional Integrity: Provides exceptional dimensional stability due to the synergistic effect of high fiber content and the low hygroscopicity of the PA12 matrix.
✅ Consistent Performance Across Temperature Ranges: Maintains mechanical properties reliably from below freezing up to its elevated heat deflection temperature.
Industrieanwendungen:
Explore the PA12 Carbon Fiber Series in Detail
Klicken Sie auf die nachstehenden Links, um umfassende technische Daten, Hauptvorteile und Anwendungsdetails für jede einzelne Sorte anzuzeigen.
| Klasse | Am besten für | Übersicht | Vollständige Details |
|---|---|---|---|
| PA12 CF10 | Cost-effective enhancement of stiffness & dimensional stability for parts in wet or chemical environments. | The most accessible CF grade for PA12, offering a sustainable upgrade with enhanced stiffness while retaining exceptional low moisture absorption and chemical resistance. | View PA12 CF10 Full Data Sheet → |
| PA12 CF20 | Components requiring a balance of rigidity, impact strength at low temperatures, and resistance to hydrolysis. | A balanced performer, excelling in damp or chemically aggressive environments where dimensional stability and durability are key. | View PA12 CF20 Full Data Sheet → |
| PA12 CF30 | Structural parts exposed to moisture, chemicals, or requiring consistent performance over a wide temperature range. | The performance benchmark, providing an optimal balance of high stiffness, superior low-temperature toughness, and outstanding environmental resistance. | View PA12 CF30 Full Data Sheet → |
| PA12 CF40 | High-precision, rigid parts where maximum dimensional stability in humid or variable conditions is critical. | Engineered for extreme rigidity and exceptional dimensional stability from a polymer with inherently low water uptake, for the most demanding technical applications. | View PA12 CF40 Full Data Sheet → |
| PA12 CF50 | Mission-critical applications demanding peak performance in harsh environments with minimal moisture sensitivity. | The pinnacle grade, delivering top stiffness and functional performance from a material known for its stability and resistance in challenging conditions. | View PA12 CF50 Full Data Sheet → |
Benötigen Sie fachkundigen Rat? Kontakt zu unserem Ingenieurteam um Ihre spezifischen Anwendungs- und Materialanforderungen zu besprechen.
Powering Innovation Across Industries (PA12 CF Series)
| Industrie | Wichtige Anwendungen |
|---|---|
| Automotive & Fluid Systems | Fuel line quick connectors, structural brackets in wet underbody areas, sensor housings exposed to road spray, charge air cooler components requiring chemical resistance. Entdecken Sie Lösungen für die Automobilindustrie → |
| Energy, Oil & Gas | Components for downhole tools, sensor and connector protectors in subsea environments, valve and manifold parts resistant to sour gas and chemicals. Siehe Industrielle Nutzung → |
| Industrial & Precision Equipment | Gears, bearings, and pump housings in lubricated or humid environments, robotic components for wash-down areas, high-precision parts for medical and fluid handling devices. Erkundigen Sie sich nach besonderen Verwendungszwecken → |
| Elektrisch & Spezialisiert | Connectors and enclosures for harsh outdoor or industrial environments, cable management systems in high-humidity settings, components requiring stable dielectric properties in varying climates. Contact for Electrical Solutions → |
How to Choose the Right PA12 CF Grade?
In einfachen Worten:
For a cost-effective upgrade into a dimensionally stable, chemical-resistant carbon fiber composite, betrachten PA12 CF10.
For the optimal balance of enhanced stiffness, excellent low-temperature impact strength, and unwavering resistance to moisture and chemicals, wählen PA12 CF30. It is the performance benchmark for most demanding applications in harsh environments.
For the ultimate stiffness and dimensional precision from a material with minimal hygroscopicity, betrachten PA12 CF50.
Sie sind sich nicht sicher, welche für Ihre Rolle perfekt ist? Beschreiben Sie unseren Ingenieuren Ihre Anwendung, um eine maßgeschneiderte Empfehlung zu erhalten.
Warum uns wählen?
PA12 CF30 FAQ
Q1: Why is PA12 CF30 considered a ‘benchmark’ for harsh environments?
PA12 CF30 achieves the best practical balance of properties needed for structural parts in aggressive conditions: high stiffness from carbon fiber, sufficient toughness, and the inherent stability and chemical resistance of PA12. It is the most commonly specified grade for demanding applications where PA6 or PA66 would be compromised by moisture or chemicals.
Q2: What are typical applications for PA12 CF30?
It is widely used in: Oil & Gas (components for downhole tools, sensor housings), Automobilindustrie (fuel system structural parts, charge air cooler components), Industrial Valves & Pumps, und Marine/Offshore Equipment. Anywhere long-term exposure to moisture, salts, or chemicals is combined with structural needs.
Q3: How does its weathering resistance compare to other nylons?
PA12 generally has better resistance to hydrolysis and thermal aging than PA6 or PA66. While UV stabilization is still needed for direct sunlight exposure, its bulk properties are less affected by long-term heat and humidity exposure, making it more suitable for outdoor technical components.
